Car Wiring Diagrams for Power windows circuit for Audi A4 B8 facelift (2011-2015)

BLK/GRN WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/VIO WIRE BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DRIVER WINDOW REGULATOR MOTOR DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR) FRONT PASSENGER WINDOW REGULATOR MOTOR FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S FRONT DOOR) FUSE 11 FUSE 8 FUSE 9 FUSE CARRIER 2 FUSE CARRIER 3 FUSE PANEL C (BEHIND LEFT END OF DASH) GRN/YEL WIRE GROUND DISTRIBUTION SYSTEM HOT AT ALL TIMES ORG/BRN WIRE ORG/GRN WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY/FUSE PANEL F (RIGHT SIDE OF LUGGAGE COMPT) RIGHT FRONT WINDOW REGULATOR SWITCH VIO/BLK WIRE VIO/GRY WIRE YEL/BLK WIRE

BLK/GRN WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/VIO WIRE BRN WIRE BRN/GRN WIRE CHILD SAFETY LOCK BUTTON DRIVER'S DOOR POWER WINDOW CONTROL HEAD GRN/YEL WIRE LEFT FRONT WINDOW REGULATOR SWITCH LEFT REAR DOOR CONTROL MODULE (IN LEFT REAR DOOR) LEFT REAR POWER WINDOW SWITCH LEFT REAR WINDOW REGULATOR MOTOR LEFT REAR WINDOW REGULATOR SWITCH RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT WINDOW REGULATOR SWITCH RIGHT REAR DOOR CONTROL MODULE (IN RIGHT REAR DOOR) RIGHT REAR WINDOW REGULATOR MOTOR RIGHT REAR WINDOW REGULATOR SWITCH RIGHT REAR WINDOW SWITCH SWITCH ILLUMINATION BULB VIO/GRY WIRE YEL/BLK WIRE
