Audi A4 B8 facelift (2011-2015) multimedia system preparation connector Wiring diagrams
This page contains all the electrical diagrams for the component. multimedia system preparation connector, in which he is found in the car Audi A4 B8 facelift (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram multimedia system preparation connector (1 of 2)
ANTENNA AMPLIFIER 2 (SEDAN) (RIGHT REAR OF ROOF)
ANTENNA AMPLIFIER 3 (SEDAN: LEFT SIDE OF TRUNK) (WAGON: LEFT SIDE OF CARGO AREA)
ANTENNA AMPLIFIER 4 (WAGON) (LEFT SIDE OF CARGO AREA)
AUXILIARY HEATER RADIO RECEIVER (IF EQUIPPED)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM ANTENNA
COMFORT SYSTEM CONTROL (RIGHT MODULE "C" (RIGHT SIDE PILLAR) OF TRUNK)
COMPUTER DATA LINES SYSTEM
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 8
FUSE CARRIER 5 FUSE 5
GPS SYSTEM ANTENNA
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
MOST DATA BUS CIRCUIT
MULTIMEDIA SYSTEM PREPARATION CONNECTOR
NCA WIRE
ORG/ WIRE
RADIO (IF EQUIPPED)
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY/FUSE PANEL F (RIGHT SIDE OF LUGGAGE COMPT)
SATELLITE ANTENNA
SEDAN WAGON
TELEPHONE ANTENNA
TV TUNER (IF EQUIPPED) (LEFT SIDE OF TRUNK)
W/ AUX-IN CONNECTION
W/O AUX-IN CONNECTION
WHT WIRE
YEL WIRE
Go to component -> Multimedia interface circuit (2 of 2) -> MULTIMEDIA SYSTEM PREPARATION CONNECTOR
Wiring diagram multimedia system preparation connector (2 of 2)
