Audi A4 B8 facelift (2011-2015) left multi-function buttons on steering wheel Wiring diagram
This page shows the only wiring diagram for the component.left multi-function buttons on steering wheel, which is found in the car Audi A4 B8 facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left multi-function buttons on steering wheel (1 of 1)
AIR BAG SPIRAL SPRING/RETURN SPRING (W/ SLIP RING) (IN STEERING COLUMN)
BEHIND STEERING WHEEL)
BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 5
FUSE CARRIER 1
FUSE CARRIER 2 FUSE 12
FUSE PANEL D (BEHIND RIGHT END OF DASH)
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
MODE
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/WHT WIRE
RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
STEERING COLUMN ELECTRONICS CONTROL MODULE (ON STEERING COLUMN,
STEERING WHEEL CONTROL UNIT
STEERING WHEEL VIBRATION MOTOR (W/ LANE ASSIST)
TIPTRONIC DOWNSHIFT BUTTON ON STEERING WHEEL (W/ TIPTRONIC)
TIPTRONIC UPSHIFT BUTTON ON STEERING WHEEL (W/ TIPTRONIC)
W/ TIPTRONIC W/ LANE ASSIST
Go to component: -> A/t circuit, 8 speed a/t (2 of 2) -> LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
