Audi A4 B8 facelift (2011-2015) driver's seat heater left front seat temp sensor Wiring diagram

This page shows the only wiring diagram for the component.driver's seat heater left front seat temp sensor, which is found in the car Audi A4 B8 facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver's seat heater left front seat temp sensor (1 of 1)

Wiring diagram driver's seat heater left front seat temp sensor for Audi A4 B8 facelift (2011-2015)

Get access

BACKREST HEATING ELEMENT BACKREST SIDE BOLSTER HEATER (IF EQUIPPED) BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVER'S BACKREST HEATING ELEMENT DRIVER'S SEAT HEATER LEFT FRONT SEAT TEMP SENSOR FRONT PASSENGER'S BACKREST HEATING ELEMENT FRONT PASSENGER'S SEAT HEATER FUSE FUSE CARRIER 2 FUSE PANEL C (BEHIND LEFT END OF DASH) GRN WIRE GRN/BRN WIRE HEATED DRIVER'S SEAT ADJUSTER HEATED FRONT PASSENGER'S SEAT ADJUSTER HOT AT ALL TIMES ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RIGHT FRONT SEAT TEMP SENSOR SEAT BOLSTER HEATER (IF EQUIPPED) SEAT HEATING ELEMENT SIDE BOLSTER HEATER (IF EQUIPPED) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) WHT WIRE YEL WIRE YEL/BLU WIRE

Go to component: -> Front heated seats circuit, without memory seats without ventilation -> DRIVER'S SEAT HEATER LEFT FRONT SEAT TEMP SENSOR
