Audi A4 B8 facelift (2011-2015) directional stabilization assistance windshield defogger Wiring diagram
This page shows the only wiring diagram for the component.directional stabilization assistance windshield defogger, which is found in the car Audi A4 B8 facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram directional stabilization assistance windshield defogger (1 of 1)
BLK/BRN WIRE
BLK/YEL WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
CHANGE LANE
COMPUTER DATA LINES SYSTEM
DIRECTIONAL STABILIZATION ASSISTANCE WINDSHIELD DEFOGGER
DRIVER'S EXTERIOR MIRROR ASSEMBLY
FRONT PASSENGER'S EXTERIOR MIRROR ASSEMBLY
FUSE 4
FUSE CARRIER 1 FUSE 11
FUSE PANEL C (BEHIND LEFT END OF DASH)
GRY/BLU WIRE
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LANE CHANGE
LANE CHANGE ASSISTANCE BUTTON
LANE CHANGE ASSISTANCE CONTROL MODULE (BEHIND RIGHT SIDE OF REAR BUMPER)
LANE CHANGE ASSISTANCE CONTROL MODULE 2 (BEHIND LEFT SIDE OF REAR BUMPER)
LANE CHANGE ASSISTANCE IND LAMP
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRY WIRE
VIO/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component: -> Lane departure warning circuit -> DIRECTIONAL STABILIZATION ASSISTANCE WINDSHIELD DEFOGGER
