Audi A4 B8 facelift (2011-2015) cruise control switch Wiring diagram
This page shows the only wiring diagram for the component.cruise control switch, which is found in the car Audi A4 B8 facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control switch (1 of 1)
AIR BAG CONTROL MODULE (BELOW CENTER CONSOLE)
BLK WIRE
BLU/GRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
CRUISE CONTROL SYSTEM
DRIVER'S AIR BAG IGNITER
DRIVER'S SIGNAL HORN AIR BAG ACTIVATION IGNITER 2
FUNCTION BUTTONS
FUSE 12
FUSE 5
FUSE CARRIER 1
FUSE CARRIER 2
FUSE PANEL D (BEHIND RIGHT END OF DASH)
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
IGNITION/ STARTER SWITCH
LEFT MULTI-
MODE
MODE SWITCH
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/WHT WIRE
RIGHT MULTI-FUNCTION BUTTONS
STEERING ANGLE SENSOR (BEHIND
STEERING WHEEL CONTROL UNIT
STEERING WHEEL VIBRATION MOTOR
STEERING WHEEL)
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON (IF EQUIPPED)
TURN SIGNAL SWITCH
W/ TIPTRONIC
WHT WIRE
WINDSHIELD WIPER/ INTERMITTENT
YEL WIRE
Go to component: -> Steering column electronic systems control module circuit -> CRUISE CONTROL SWITCH
