Radio circuit, mmi 2 basic for Audi A4 B8 (2007-2012)

7 16 18 PIN CONNECTOR (W/O SPEAKER PHONE) BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE CD CHANGER COMPUTER DATA LINES SYSTEM EXTERNAL AUDIO SOURCE CONNECTION (W/ MMI HIGH) FRONT INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE FUSE 1 FUSE 5 FUSE CARRIER 2 FUSE CARRIER 3 FUSE 4 FUSE CARRIER 5 GRN/VIO WIRE HOT AT ALL TIMES LEFT FRONT MID-BASS SPEAKER LEFT FRONT TREBLE SPEAKER LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT) MOST DATA BUS CIRCUIT NCA WIRE PASSENGER'S SIDE FUSE PANEL (BEHIND RIGHT END OF DASH) REAR VIEW CAMERA SYSTEM CONTROL MODULE (IF EQUIPPED) (RIGHT SIDE OF TRUNK) RED/BLK WIRE RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MID-BASS SPEAKER RIGHT FRONT TREBLE SPEAKER TV TUNER (LEFT SIDE OF TRUNK) W/ MMI HIGH WHT WIRE WHT/GRN WIRE WHT/RED WIRE

ANTENNA AMPLIFIER 2 (RIGHT REAR OF ROOF) ANTENNA AMPLIFIER 3 (SEDAN: LEFT SIDE OF TRUNK) (AVANT: LEFT SIDE OF CARGO AREA) BLK WIRE BLK/GRN WIRE BLU/GRN WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT MULTIMEDIA FRONT PASSENGER'S SEAT MULTIMEDIA FUSE 5 FUSE 6 FUSE CARRIER 4 FUSE CARRIER 5 GRN/VIO WIRE HOT AT ALL TIMES HOT W/ SOCKETS RELAY ENERGIZED LEFT REAR MID/LOW RANGE SPEAKER LEFT REAR TREBLE SPEAKER LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT) MOST DATA BUS CIRCUIT NAVIGATION SYSTEM W/ CD DRIVE CONTROL MODULE (LEFT SIDE OF TRUNK) NCA WIRE RADIO RED/VIO WIRE RED/YEL WIRE RIGHT REAR MID/LOW RANGE SPEAKER RIGHT REAR TREBLE SPEAKER SATELLITE ANTENNA SATELLITE RADIO (LEFT REAR OF TRUNK) W/ BLUETOOTH CELLULAR TELEPHONE W/ SPEAKER PHONE WHT/GRN WIRE
