Radio circuit, basic infotainment for Audi A4 B8 (2007-2012)

18 PIN CONNECTOR ANTENNA AMPLIFIER ANTENNA AMPLIFIER 3 (SEDAN: LEFT SIDE OF TRUNK) (AVANT: LEFT SIDE OF CARGO AREA) BLK WIRE BLK/RED WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM EXTERNAL AUDIO SOURCE CONNECTION FUSE 1 FUSE 3 FUSE CARRIER 2 GRN WIRE GRN/BLU WIRE GRY WIRE HOT AT ALL TIMES NCA WIRE ORG/BRN WIRE ORG/VIO WIRE PASSENGER'S SIDE FUSE PANEL (BEHIND RIGHT END OF DASH) RADIO RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE SATELLITE ANTENNA TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT) W/ SPEAKER PHONE W/O SPEAKER PHONE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/RED WIRE

BLK/RED WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE CD/DVD CHANGER COMPUTER DATA LINES SYSTEM FUSE 1 FUSE CARRIER 2 GRN/BLU WIRE GRN/VIO WIRE HOT AT ALL TIMES LEFT FRONT MID-BASS SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR MID/LOW RANGE SPEAKER LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT NCA WIRE PASSENGER'S SIDE FUSE PANEL (BEHIND RIGHT END OF DASH) RED/BLK WIRE RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MID-BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR MID/LOW RANGE SPEAKER RIGHT REAR TREBLE SPEAKER WHT/BLU WIRE WHT/GRN WIRE
