Audi A4 B8 (2007-2012) w/ rear view camera Wiring diagrams
This page contains all the electrical diagrams for the component. w/ rear view camera, in which he is found in the car Audi A4 B8 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/ rear view camera wiring diagram (1 of 11)
18-PIN CONNECTOR (NOT USED)
BLK WIRE
BLU WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT INFORMATION DISPLAY CONTROL HEAD
FRONT INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE (BEHIND GLOVE BOX)
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HOT AT ALL TIMES FUSE FUSE 5 CARRIER 3
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
MULTIMEDIA CONTROL HEAD
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/GRN WIRE
ORG/RED WIRE
ORG/VIO WIRE
ORG/WHT WIRE
POWER DISTRIBUTION SYSTEM
REAR VIEW CAMERA SYSTEM CONTROL MODULE (RIGHT SIDE OF TRUNK)
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
SOUND SYSTEMS
TV TUNER (IF EQUIPPED) (LEFT SIDE OF TRUNK)
VIO WIRE
W/ REAR VIEW CAMERA
W/O REAR VIEW CAMERA
WHT WIRE
YEL WIRE
Go to component -> Front information display control module circuit, high -> W/ REAR VIEW CAMERA
w/ rear view camera wiring diagram (2 of 11)
16 7 18-PIN CONNECTOR (W/O HANDSFREE SPEAKING SYSTEM)
ANTENNA AMPLIFIER 3 (SEDAN: LEFT SIDE OF TRUNK) (AVANT: LEFT SIDE OF CARGO AREA)
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
FUSE CARRIER 5
GRN/VIO WIRE
HOT AT ALL TIMES FUSE 3
HOT AT ALL TIMES FUSE 5
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
MOST DATA BUS CIRCUIT
NCA WIRE
RADIO
RED WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT MID-BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID/ LOW RANGE SPEAKER
RIGHT REAR TREBLE SPEAKER
TV TUNER (IF EQUIPPED) (LEFT SIDE OF TRUNK)
VIO WIRE
W/ REAR VIEW CAMERA
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Navigation circuit, mmi 3 basic (1 of 2) -> W/ REAR VIEW CAMERA
w/ rear view camera wiring diagram (3 of 11)
BLK/GRN WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
CD/DVD CHANGER
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA ANTENNA AMPLIFIER 2 (RIGHT REAR OF ROOF)
DRIVER'S SEAT MULTIMEDIA
FRONT PASSENGER'S SEAT MULTIMEDIA
FUSE 1
FUSE CARRIER 2
FUSE CARRIER 4 FUSE 6
GRN/VIO WIRE
HOT AT ALL TIMES
HOT W/ SOCKETS RELAY ENERGIZED
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT MID-BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR MID/ LOW RANGE SPEAKER
LEFT REAR TREBLE SPEAKER
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM ANTENNA
NCA WIRE
PASSENGER'S SIDE FUSE PANEL (BEHIND RIGHT END OF DASH)
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (CENTER REAR OF ROOF)
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
SATELLITE ANTENNA
TELEPHONE ANTENNA
TELEPHONE BASE PLATE
W/ BLUETOOTH
W/ REAR VIEW CAMERA
W/ SPEAKER PHONE
Go to component -> Navigation circuit, mmi 3 basic (2 of 2) -> W/ REAR VIEW CAMERA
w/ rear view camera wiring diagram (4 of 11)
ANTENNA AMPLIFIER 3 (SEDAN: LEFT SIDE OF TRUNK) (AVANT: LEFT SIDE OF CARGO AREA)
BLK WIRE
BRN WIRE
CD/DVD CHANGER
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA ANTENNA AMPLIFIER 2 (RIGHT REAR OF ROOF)
FUSE 1
FUSE 5
FUSE CARRIER 2
FUSE CARRIER 5 FUSE 3
GRN/VIO WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
LUGGAGE COMPT)
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM ANTENNA
NCA WIRE
OF ROOF)
PASSENGER'S SIDE FUSE PANEL (BEHIND RIGHT END OF DASH)
RADIO
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (CENTER REAR
RED/BLK WIRE
RED/VIO WIRE
SATELLITE ANTENNA
TELEPHONE ANTENNA
TELEPHONE BASE PLATE
TV TUNER (IF EQUIPPED) (LEFT SIDE OF TRUNK)
W/ BLUETOOTH
W/ REAR VIEW CAMERA
W/ SPEAKER PHONE
WHT/RED WIRE
Go to component -> Navigation circuit, mmi 3 premium (1 of 2) -> W/ REAR VIEW CAMERA
w/ rear view camera wiring diagram (5 of 11)
16 7 18-PIN CONNECTOR (W/O HANDSFREE SPEAKING SYSTEM)
ANTENNA AMPLIFIER 3 (SEDAN: LEFT SIDE OF TRUNK) (AVANT: LEFT SIDE OF CARGO AREA)
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CENTER MID/HIGH RANGE SPEAKER
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
FUSE CARRIER 5
GRN/VIO WIRE
HOT AT ALL TIMES FUSE 3
HOT AT ALL TIMES FUSE 5
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
MOST DATA BUS CIRCUIT
NCA WIRE
RADIO
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT MID-BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID/ LOW RANGE SPEAKER
RIGHT REAR TREBLE SPEAKER
SUBWOOFER
TV TUNER (IF EQUIPPED) (LEFT SIDE OF TRUNK)
W/ REAR VIEW CAMERA
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
Go to component -> Navigation circuit, mmi 3 standard (1 of 2) -> W/ REAR VIEW CAMERA
w/ rear view camera wiring diagram (6 of 11)
BLK/GRN WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
CD/DVD CHANGER
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA ANTENNA AMPLIFIER 2 (RIGHT REAR OF ROOF)
DRIVER'S SEAT MULTIMEDIA
FRONT PASSENGER'S SEAT MULTIMEDIA
FUSE 1
FUSE CARRIER 2
FUSE CARRIER 4 FUSE 6
GRN/VIO WIRE
HOT AT ALL TIMES
HOT W/ SOCKETS RELAY ENERGIZED
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT MID-BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR MID/ LOW RANGE SPEAKER
LEFT REAR TREBLE SPEAKER
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM ANTENNA
NCA WIRE
PASSENGER'S SIDE FUSE PANEL (BEHIND RIGHT END OF DASH)
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (CENTER REAR OF ROOF)
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
SATELLITE ANTENNA
TELEPHONE ANTENNA
TELEPHONE BASE PLATE
W/ BLUETOOTH
W/ REAR VIEW CAMERA
W/ SPEAKER PHONE
Go to component -> Navigation circuit, mmi 3 standard (2 of 2) -> W/ REAR VIEW CAMERA
w/ rear view camera wiring diagram (7 of 11)
16 7 18-PIN CONNECTOR (W/O HANDSFREE SPEAKING SYSTEM)
ANTENNA AMPLIFIER 3 (SEDAN: LEFT SIDE OF TRUNK) (AVANT: LEFT SIDE OF CARGO AREA)
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
FUSE CARRIER 5
GRN/VIO WIRE
HOT AT ALL TIMES FUSE 3
HOT AT ALL TIMES FUSE 5
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
MOST DATA BUS CIRCUIT
NCA WIRE
RADIO
RED WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT MID-BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID/ LOW RANGE SPEAKER
RIGHT REAR TREBLE SPEAKER
TV TUNER (IF EQUIPPED) (LEFT SIDE OF TRUNK)
VIO WIRE
W/ REAR VIEW CAMERA
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Radio circuit, mmi 3 basic (1 of 2) -> W/ REAR VIEW CAMERA
w/ rear view camera wiring diagram (8 of 11)
BLK/GRN WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
CD/DVD CHANGER
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA ANTENNA AMPLIFIER 2 (RIGHT REAR OF ROOF)
DRIVER'S SEAT MULTIMEDIA
FRONT PASSENGER'S SEAT MULTIMEDIA
FUSE 1
FUSE CARRIER 2
FUSE CARRIER 4 FUSE 6
GRN/VIO WIRE
HOT AT ALL TIMES
HOT W/ SOCKETS RELAY ENERGIZED
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT MID-BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR MID/ LOW RANGE SPEAKER
LEFT REAR TREBLE SPEAKER
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM ANTENNA
NCA WIRE
PASSENGER'S SIDE FUSE PANEL (BEHIND RIGHT END OF DASH)
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (CENTER REAR OF ROOF)
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
SATELLITE ANTENNA
TELEPHONE ANTENNA
TELEPHONE BASE PLATE
W/ BLUETOOTH
W/ REAR VIEW CAMERA
W/ SPEAKER PHONE
Go to component -> Radio circuit, mmi 3 basic (2 of 2) -> W/ REAR VIEW CAMERA
w/ rear view camera wiring diagram (9 of 11)
ANTENNA AMPLIFIER 3 (SEDAN: LEFT SIDE OF TRUNK) (AVANT: LEFT SIDE OF CARGO AREA)
BLK WIRE
BRN WIRE
CD/DVD CHANGER
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA ANTENNA AMPLIFIER 2 (RIGHT REAR OF ROOF)
FUSE 1
FUSE 5
FUSE CARRIER 2
FUSE CARRIER 5 FUSE 3
GRN/VIO WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
LUGGAGE COMPT)
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM ANTENNA
NCA WIRE
OF ROOF)
PASSENGER'S SIDE FUSE PANEL (BEHIND RIGHT END OF DASH)
RADIO
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (CENTER REAR
RED/BLK WIRE
RED/VIO WIRE
SATELLITE ANTENNA
TELEPHONE ANTENNA
TELEPHONE BASE PLATE
TV TUNER (IF EQUIPPED) (LEFT SIDE OF TRUNK)
W/ BLUETOOTH
W/ REAR VIEW CAMERA
W/ SPEAKER PHONE
WHT/RED WIRE
Go to component -> Radio circuit, mmi 3 premium (1 of 2) -> W/ REAR VIEW CAMERA
w/ rear view camera wiring diagram (10 of 11)
16 7 18-PIN CONNECTOR (W/O HANDSFREE SPEAKING SYSTEM)
ANTENNA AMPLIFIER 3 (SEDAN: LEFT SIDE OF TRUNK) (AVANT: LEFT SIDE OF CARGO AREA)
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CENTER MID/HIGH RANGE SPEAKER
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
FUSE CARRIER 5
GRN/VIO WIRE
HOT AT ALL TIMES FUSE 3
HOT AT ALL TIMES FUSE 5
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
MOST DATA BUS CIRCUIT
NCA WIRE
RADIO
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT MID-BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID/ LOW RANGE SPEAKER
RIGHT REAR TREBLE SPEAKER
SUBWOOFER
TV TUNER (IF EQUIPPED) (LEFT SIDE OF TRUNK)
W/ REAR VIEW CAMERA
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
Go to component -> Radio circuit, mmi 3 standard (1 of 2) -> W/ REAR VIEW CAMERA
