Audi A4 B8 (2007-2012) seat heating element Wiring diagrams
This page contains all the electrical diagrams for the component. seat heating element, in which he is found in the car Audi A4 B8 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
seat heating element wiring diagram (1 of 3)
ADJUSTMENT
BACKREST
BACKREST HEATING ELEMENT
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
CIRCUIT BREAKER 1
DRIVER POWER SEAT
DRIVER'S BACKREST HEATING ELEMENT
DRIVER'S SEAT BACKREST FAN (TOP OF DRIVER SEAT BACKREST)
DRIVER'S SEAT BACKREST FAN 2 (MIDDLE OF DRIVER SEAT
DRIVER'S SEAT CUSHION FAN (UNDER FRONT OF DRIVER SEAT CUSHION)
DRIVER'S SEAT CUSHION FAN 2 (UNDER REAR OF DRIVER SEAT CUSHION)
DRIVER'S SEAT HEATER
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT TEMP SENSOR
MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE (UNDER DRIVER'S SEAT)
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
SEAT HEATING ELEMENT
SIDE BOLSTER HEATER
WHT WIRE
YEL WIRE
Go to component -> Front seat heater circuit, with memory seats with ventilation -> SEAT HEATING ELEMENT
seat heating element wiring diagram (2 of 3)
BACKREST HEATING ELEMENT
BACKREST SIDE BOLSTER HEATER (IF EQUIPPED)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S BACKREST HEATING ELEMENT
DRIVER'S SEAT HEATER LEFT FRONT SEAT TEMP SENSOR
DRIVER'S SIDE FUSE PANEL (BEHIND LEFT END OF DASH)
FRONT PASSENGER'S BACKREST HEATING ELEMENT
FRONT PASSENGER'S SEAT HEATER
FUSE
FUSE CARRIER 2
GRN WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT SEAT TEMP SENSOR
SEAT HEATING ELEMENT
SIDE BOLSTER HEATER (IF EQUIPPED)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Front seat heater circuit, without ventilation -> SEAT HEATING ELEMENT
seat heating element wiring diagram (3 of 3)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
FUSE
FUSE CARRIER 3
FUSE CARRIER 4
GRN WIRE
GRY/BLU WIRE
HEATED SEAT TEMPERATURE SENSOR
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR HEATED SEAT REGULATING SWITCH
LEFT REAR SEAT HEATER
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR HEATED SEAT REGULATING SWITCH
RIGHT REAR SEAT HEATER
SEAT HEATING ELEMENT
SEAT OCCUPIED SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
VIO WIRE
VIO/RED WIRE
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Rear seat heater circuit -> SEAT HEATING ELEMENT
