Audi A4 B8 (2007-2012) roof blind control module Wiring diagrams

This page contains all the electrical diagrams for the component. roof blind control module, in which he is found in the car Audi A4 B8 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram roof blind control module (1 of 2)

Wiring diagram roof blind control module for Audi A4 B8 (2007-2012)

Get access

3.0L ACTIVE STEERING CONTROL MODULE BLK WIRE BRN WIRE DRIVER'S BACKREST HEATING ELEMENT, DRIVER'S SEAT BACKREST SIDE BOLSTER ELEMENT ELECTRO- MECHANICAL POWER STEERING MOTOR SHIELD ENGINE CONTROL MODULE (ECM), SUPPRESSOR FM FREQUENCY FILTER (-) FUEL PUMP (FP) CONTROL MODULE LEFT FRONT OUTSIDE DOOR HANDLE TOUCH SENSOR LEFT FRONT SEAT VENTILATION CONTROL MODULE, DRIVER'S SEAT SIDE BOLSTER HEATER LEFT REAR OUTSIDE DOOR HANDLE TOUCH SENSOR RIGHT FRONT OUTSIDE DOOR HANDLE TOUCH SENSOR ROOF BLIND CONTROL MODULE

Go to component: -> Ground distribution circuit (3 of 3) -> ROOF BLIND CONTROL MODULE

Wiring diagram roof blind control module (2 of 2)

Wiring diagram roof blind control module for Audi A4 B8 (2007-2012)

Get access

BLK WIRE BLK/BRN WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SIDE FUSE PANEL (BEHIND LEFT END OF DASH) FUSE 9 FUSE CARRIER 3 FUSE 11 GRN WIRE GRY WIRE HOT AT ALL TIMES POWER SUNROOF CONTROL MODULE (CENTER FRONT OF ROOF) RED WIRE RED/BLK WIRE RED/BLU WIRE ROOF BLIND CONTROL MODULE SUNROOF MOTOR SUNROOF REGULATOR VIO WIRE WHT WIRE YEL WIRE YEL/RED WIRE

Go to component: -> Power top/sunroof circuit, with roof blind -> ROOF BLIND CONTROL MODULE
