Audi A4 B8 (2007-2012) red Wiring diagrams

This page contains all the electrical diagrams for the component. red, in which he is found in the car Audi A4 B8 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram red (51 of 68)

Go to component: -> Charging circuit -> RED WIRE

Wiring diagram red (52 of 68)

Go to component: -> Multimedia interface circuit (1 of 2) -> RED WIRE

Wiring diagram red (53 of 68)

Go to component: -> Multimedia interface circuit (2 of 2) -> RED WIRE

Wiring diagram red (54 of 68)

Go to component: -> Power top/sunroof circuit, with roof blind -> RED WIRE

Wiring diagram red (55 of 68)

Go to component: -> Radio circuit, mmi 3 basic (1 of 2) -> RED WIRE

Wiring diagram red (56 of 68)

Go to component: -> Radio circuit, premium infotainment (2 of 2) -> RED WIRE

Wiring diagram red (57 of 68)

Go to component: -> Radio circuit, standard infotainment (2 of 2) -> RED WIRE

Wiring diagram red (58 of 68)

2.0L 3.0L BATTERY BATTERY INTERRUPT IGNITER BATTERY JUMP BATTERY MONITORING CONTROL MODULE (MIDDLE OF LUGGAGE COMPT, ON BATTERY) BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE CHARGING CIRCUIT CLUTCH POSITION SENSOR COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE COMPUTER DATA LINES SYSTEM DRIVER'S SIDE FUSE PANEL E-BOX RELAY/ FUSE CARRIER (IN PLENUM CHAMBER ELECTRONICS BOX) ENGINE CONTROL MODULE (ECM) (2.0L: LEFT SIDE OF ENGINE COMPT PLENUM CHAMBER) ENGINE CONTROLS SYSTEM FUSE FUSE 1 FUSE 10 FUSE 16 FUSE CARRIER FUSE CARRIER 1 FUSE CARRIER 2 FUSE PANEL GRN/GRY WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/WHT WIRE HOT W/ MOTRONIC ENGINE CONTROL MODULE (ECM) POWER SUPPLY RELAY ENERGIZED HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED M/T NCA WIRE OF TRUNK) ORG/BLK WIRE ORG/BRN WIRE POWER DISTRIBUTION SYSTEM POWER SUPPLY RELAY (TERMINAL 15) (ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE PRNDS RED WIRE RED/BLK WIRE RED/BRN WIRE RELAY/FUSE CARRIER SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ON SHIFTER UNIT) SHIFT INTERLOCK SYSTEM SOCKETS RELAY (LUGGAGE COMPT RELAY/FUSE CARRIER) STARTER STARTER RELAY (ON E-BOX RELAY/FUSE CARRIER) STARTER RELAY 2 (ON E-BOX RELAY/FUSE CARRIER) SUPPLEMENTAL RESTRAINTS SYSTEM TERMINAL (MIDDLE OF ENGINE COMPT PLENUM CHAMBER) TRANSMISSION CONTROL MODULE (TCM) DIRECT SHIFT GEARBOX (DSG) MECHATRONIC VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) VIO/GRY WIRE W/ 6 SPEED A/T W/ CVT W/ DIRECT SHIFT GEARBOX W/O DIRECT SHIFT GEARBOX

Go to component: -> Starting circuit -> RED WIRE

Wiring diagram red (59 of 68)

Go to component: -> Steering column circuit -> RED WIRE

Wiring diagram red (60 of 68)

Go to component: -> Supplemental restraints circuit (1 of 3) -> RED WIRE

Page 6 of 7
