Audi A4 B8 (2007-2012) prnds Wiring diagrams
This page contains all the electrical diagrams for the component. prnds, in which he is found in the car Audi A4 B8 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
prnds wiring diagram (1 of 5)
ACCESS/START AUTHORIZATION BUTTON (W/ START/STOP BUTTON)
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
COMFORT SYSTEM CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE FUSE PANEL (BEHIND LEFT END OF DASH)
ENGINE 1 2 3 4 5 6 7 8 9 CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM
FUSE 1
FUSE CARRIER 1 FUSE 10
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
PRNDS
RED WIRE
RED/BRN WIRE
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ON SHIFTER UNIT)
TRANSMISSION CONTROL MODULE (TCM) (IN MECHATRONIC UNIT)
TRANSMISSION PARK SELECTOR SWITCH, SHIFT LOCK SOLENOID
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
VIO WIRE
YEL WIRE
Go to component -> A/t circuit, 6 speed a/t -> PRNDS
prnds wiring diagram (2 of 5)
2.0L
ACCESS/START AUTHORIZATION BUTTON (W/ START/STOP BUTTON)
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
COMFORT SYSTEM CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM
DRIVER'S SIDE FUSE PANEL (BEHIND LEFT END OF DASH)
ENGINE CONTROLS SYSTEM
FUSE
FUSE CARRIER 1 FUSE 10
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
PRNDS
RED WIRE
RED/BRN WIRE
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ON SHIFTER UNIT)
TRANSMISSION CONTROL MODULE (TCM) (IN MECHATRONIC UNIT)
TRANSMISSION PARK SELECTOR SWITCH, SHIFT LOCK SOLENOID
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
VIO WIRE
YEL WIRE
Go to component -> A/t circuit, with cvt -> PRNDS
prnds wiring diagram (3 of 5)
6 SPEED A/T
AUTOMATIC DAY/ NIGHT INTERIOR MIRROR
BACKUP LAMP
BACKUP LAMP BACKUP LAMP
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMFORT SYSTEM CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
CVT
DIRECT SHIFT GEARBOX (DSG) MECHATRONIC
FUSE 8
FUSE CARRIER 2
GRN/VIO WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT REAR TAILLAMP ASSEMBLY 1
LEFT REAR TAILLAMP ASSEMBLY 2
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PRNDS
RIGHT REAR TAILLAMP ASSEMBLY 1
RIGHT REAR TAILLAMP ASSEMBLY 2
SEDAN
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ON SHIFTER UNIT)
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION CONTROL MODULE (TCM) (IN MECHATRONIC UNIT)
W/ DIRECT SHIFT GEAR BOX
W/ LED REAR LIGHTS
W/O DIRECT SHIFT GEAR BOX
WAGON
YEL/RED WIRE
Go to component -> Backup lamps circuit -> PRNDS
prnds wiring diagram (4 of 5)
2.0L
3.0L
ACCESS/START AUTHORIZATION BUTTON
BLU/GRY WIRE
BRN WIRE
CLIMATRONIC CONTROL MODULE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF TRUNK)
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE FUSE PANEL (BEHIND LEFT END OF DASH)
FUSE
FUSE CARRIER 1
GRN/VIO WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
PRNDS
RED/BLK WIRE
RED/BRN WIRE
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ON SHIFTER UNIT)
TRANSMISSION CONTROL MODULE (TCM) DIRECT SHIFT GEARBOX (DSG) MECHATRONIC
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
W/ 6 SPEED A/T
W/ CVT
W/ DIRECT SHIFT
W/O DIRECT SHIFT
Go to component -> Shift interlock circuit -> PRNDS
prnds wiring diagram (5 of 5)
2.0L
3.0L
BATTERY
BATTERY INTERRUPT IGNITER
BATTERY JUMP
BATTERY MONITORING CONTROL MODULE (MIDDLE OF LUGGAGE COMPT, ON BATTERY)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
CHARGING CIRCUIT
CLUTCH POSITION SENSOR
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE FUSE PANEL
E-BOX RELAY/ FUSE CARRIER (IN PLENUM CHAMBER ELECTRONICS BOX)
ENGINE CONTROL MODULE (ECM) (2.0L: LEFT SIDE OF ENGINE COMPT PLENUM CHAMBER)
ENGINE CONTROLS SYSTEM
FUSE
FUSE 1
FUSE 10 FUSE 16
FUSE CARRIER
FUSE CARRIER 1
FUSE CARRIER 2
FUSE PANEL
GRN/GRY WIRE
GRN/VIO WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT W/ MOTRONIC ENGINE CONTROL MODULE (ECM) POWER SUPPLY RELAY ENERGIZED
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
M/T
NCA WIRE
OF TRUNK)
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
POWER SUPPLY RELAY (TERMINAL 15) (ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
PRNDS
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RELAY/FUSE CARRIER
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ON SHIFTER UNIT)
SHIFT INTERLOCK SYSTEM
SOCKETS RELAY (LUGGAGE COMPT RELAY/FUSE CARRIER)
STARTER
STARTER RELAY (ON E-BOX RELAY/FUSE CARRIER)
STARTER RELAY 2 (ON E-BOX RELAY/FUSE CARRIER)
SUPPLEMENTAL RESTRAINTS SYSTEM
TERMINAL (MIDDLE OF ENGINE COMPT PLENUM CHAMBER)
TRANSMISSION CONTROL MODULE (TCM) DIRECT SHIFT GEARBOX (DSG) MECHATRONIC
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
VIO/GRY WIRE
W/ 6 SPEED A/T W/ CVT
W/ DIRECT SHIFT GEARBOX
W/O DIRECT SHIFT GEARBOX
Go to component -> Starting circuit -> PRNDS
