Audi A4 B8 (2007-2012) left front microphone Wiring diagram

18 PIN CONNECTOR (W/O SPEAKER PHONE) BLK WIRE BLU WIRE BLU/VIO WIRE BLU/YEL WIRE BLUETOOTH ANTENNA (IF EQUIPPED) BRN WIRE COMPUTER DATA LINES SYSTEM FRONT INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE (BEHIND GLOVE BOX) FUSE 4 FUSE CARRIER 2 FUSE 3 FUSE FUSE 5 CARRIER 5 GRN WIRE GRN/VIO WIRE GRY/BLU WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT FRONT MICROPHONE LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT) MICROPHONE UNIT (IN FRONT OF MODULE) MMI BASIC MMI HIGH MOST DATA BUS CIRCUIT MULTIMEDIA CONTROL HEAD NCA WIRE ORG/ WIRE PANEL (BEHIND RIGHT END OF DASH) PASSENGER'S SIDE FUSE REAR VIEW CAMERA SYSTEM CONTROL MODULE (IF EQUIPPED) (RIGHT SIDE OF TRUNK) RED WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RIGHT FRONT MICROPHONE TELEPHONE BASEPLATE (W/ SPEAKER) TELEPHONE BASEPLATE (W/O SPEAKER) VEHICLE ELECTRIC SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) VIO RED/ WIRE VIO/YEL WIRE W/ SPEAKER W/O SPEAKER W/O W/ SPEAKER SPEAKER WHT WIRE YEL WIRE
