Audi A4 B8 (2007-2012) lane change Wiring diagram
This page shows the only wiring diagram for the component.lane change, which is found in the car Audi A4 B8 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lane change (1 of 1)
BLK/BRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
CHANGE LANE
COMPUTER DATA LINES SYSTEM
DIRECTIONAL STABILIZATION ASSISTANCE CONTROL MODULE
DIRECTIONAL STABILIZATION ASSISTANCE WINDSHIELD HEATER
DRIVER'S EXTERIOR MIRROR ASSEMBLY
DRIVER'S SIDE FUSE PANEL (BEHIND LEFT END OF DASH)
FRONT PASSENGER'S EXTERIOR MIRROR ASSEMBLY
FUSE CARRIER 1 FUSE 4
FUSE CARRIER 4 FUSE 10
GRY/BLU WIRE
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LANE CHANGE
LANE CHANGE ASSISTANCE BUTTON
LANE CHANGE ASSISTANCE CONTROL MODULE (ON LEFT TAILLIGHT ASSEMBLY)
LANE CHANGE ASSISTANCE CONTROL MODULE 2 (ON RIGHT TAILLIGHT ASSEMBLY)
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER (RIGHT SIDE OF LUGGAGE COMPT)
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRY WIRE
VIO/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Lane departure warning circuit -> LANE CHANGE
