Audi A4 B8 (2007-2012) lamp right parking Wiring diagram
This page shows the only wiring diagram for the component.lamp right parking, which is found in the car Audi A4 B8 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lamp right parking (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE FUSE PANEL (BEHIND LEFT END OF DASH)
EMERGENCY FLASHER BUTTON
EMERGENCY FLASHER INDICATOR LAMP EMERGENCY FLASHER BUTTON
FOG LAMP BUTTON LIGHT SWITCH 4 3 1 6 2
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
FUSE 10 FUSE 8
FUSE 14
FUSE 7
FUSE CARRIER 1
FUSE CARRIER 2
FUSE CARRIER 3
GRN WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEADLAMP RIGHT LOW BEAM
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT PANEL ILLUMINATION DIMMER SWITCH
LAMP
LAMP RIGHT PARKING
LEFT DAYTIME
LEFT FRONT FOG LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN
LEFT HEADLIGHT ASSEMBLY
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LEFT PARKING
MARKER LAMP
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER'S SIDE FUSE PANEL (BEHIND RIGHT END OF DASH)
REAR FOG LAMP BUTTON
RED/VIO WIRE
RED/YEL WIRE
RIGHT DAYTIME
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE
RIGHT HEADLIGHT ASSEMBLY
RIGHT HIGH BEAM HEADLAMP
RUNNING LIGHT
SENSOR PACKAGE)
SIGNAL LAMP
SIGNAL LAMP RIGHT FRONT TURN
SUPPLEMENTAL RESTRAINTS SYSTEM
VALET PARKING INDICATOR LAMP VALET PARKING LOCK BUTTON
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit, without bi-xenon headlights -> LAMP RIGHT PARKING
