Audi A4 B8 (2007-2012) driver's door control module (in driver's Wiring diagram
This page shows the only wiring diagram for the component.driver's door control module (in driver's, which is found in the car Audi A4 B8 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's door control module (in driver's (1 of 1)
ANTI-THEFT ALARM SYSTEM SENSOR
CD CHANGER, DVD CHANGER
CHARISMA SWITCH MODULE
CONTROL MODULE (BEHIND GLOVE BOX)
DIGITAL RADIO (DAB) (IF EQUIPPED)
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S
DRIVER'S SIDE CAN SEPERATING PLUG
FRONT DOOR)
FRONT INFORMATION DISPLAY CONTROL HEAD
GARAGE DOOR OPENER CONTROL HEAD
GRN WIRE
GRN/VIO WIRE
INFORMATION ELECTRONICS CONTROL MODULE 1
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE (UNDER DRIVER'S SEAT)
NAVIGATION SYSTEM W/ CD DRIVE CONTROL MODULE (LEFT SIDE OF TRUNK)
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PREMIUM STANDARD
SATELLITE RADIO (IF EQUIPPED) (LEFT REAR OF TRUNK)
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
TV TUNER (LEFT SIDE OF TRUNK)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
VIO WIRE
VIO/YEL WIRE
W/ MMI BASIC
W/ MMI HIGH
Go to component: -> Computer data lines circuit (2 of 3) -> DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S
