Audi A4 B8 (2007-2012) driver power seat Wiring diagram
This page shows the only wiring diagram for the component.driver power seat, which is found in the car Audi A4 B8 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver power seat (1 of 1)
ADJUSTMENT
BACKREST
BACKREST HEATING ELEMENT
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
CIRCUIT BREAKER 1
DRIVER POWER SEAT
DRIVER'S BACKREST HEATING ELEMENT
DRIVER'S SEAT BACKREST FAN (TOP OF DRIVER SEAT BACKREST)
DRIVER'S SEAT BACKREST FAN 2 (MIDDLE OF DRIVER SEAT
DRIVER'S SEAT CUSHION FAN (UNDER FRONT OF DRIVER SEAT CUSHION)
DRIVER'S SEAT CUSHION FAN 2 (UNDER REAR OF DRIVER SEAT CUSHION)
DRIVER'S SEAT HEATER
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT TEMP SENSOR
MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE (UNDER DRIVER'S SEAT)
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
SEAT HEATING ELEMENT
SIDE BOLSTER HEATER
WHT WIRE
YEL WIRE
Go to component: -> Front seat heater circuit, with memory seats with ventilation -> DRIVER POWER SEAT
