Audi A4 B8 (2007-2012) center rear seat belt tentioner igniter Wiring diagram

This page shows the only wiring diagram for the component.center rear seat belt tentioner igniter, which is found in the car Audi A4 B8 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram center rear seat belt tentioner igniter (1 of 1)

Wiring diagram center rear seat belt tentioner igniter for Audi A4 B8 (2007-2012)

Get access

AIR BAG CONTROL MODULE (BELOW CENTER CONSOLE) BLK WIRE BLK/BRN WIRE BLK/YEL WIRE BLU WIRE BRN WIRE CENTER REAR SEAT BELT TENTIONER IGNITER DRIVER'S HEAD CURTAIN AIR BAG IGNITER DRIVER'S SAFETY BELT SWITCH FRONT PASSENGER'S AIR BAG IGNITER 1, 2 (BEHIND RIGHT SIDE OF DASH) FRONT PASSENGER'S HEAD CURTAIN AIR BAG IGNITER GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE IGNITER LEFT REAR SEAT BELT TENTIONER IGNITER NCA WIRE RED WIRE RIGHT REAR SEAT BELT TENSIONER IGNITER SOLID STATE VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/GRY WIRE

Go to component: -> Supplemental restraints circuit (3 of 3) -> CENTER REAR SEAT BELT TENTIONER IGNITER
