Audi A4 B8 (2007-2012) brake/ tail light backup lamp Wiring diagram
This page shows the only wiring diagram for the component.brake/ tail light backup lamp, which is found in the car Audi A4 B8 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake/ tail light backup lamp (1 of 1)
3.0L 2.0L
BACKUP LAMP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRAKE/ TAIL LIGHT BACKUP LAMP
BRAKE/ TURN SIGNAL/ TAIL LAMP
BRN WIRE
CLIMATRONIC CONTROL MODULE
CLUTCH POSITION SENSOR (M/T)
DRIVER'S FUSE CARRIER 2 SIDE FUSE PANEL (BEHIND LEFT END OF DASH)
ENGINE CONTROL MODULE (ECM)
FUSE 2
GRN WIRE
GRY WIRE
GRY/WHT WIRE
HIGH MOUNT BRAKE LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR TAILLAMP ASSEMBLY 1
PARKING/ FOG LAMP
REAR FOG LAMP
REAR LID LOCK CYLINDER UNLOCK BUTTON
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RIGHT LICENSE PLATE LIGHT
RIGHT REAR TAILLAMP ASSEMBLY 2
SIDE MARKER LAMP
TAIL LAMP
TURN SIGNAL LAMP
W/ LED REAR LIGHTS
WHT WIRE
YEL WIRE
Go to component: -> Exterior lamps circuit, sedan (3 of 3) -> BRAKE/ TAIL LIGHT BACKUP LAMP
