Audi A4 B8 (2007-2012) automatic transmission hydraulic pressure sensor 1 Wiring diagram

2.0L 3.0L ACCESS/START AUTHORIZATION BUTTON (W/ START/ STOP BUTTON) AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 1 AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 2 BLK/VIO WIRE BLU/BLK WIRE BLU/GRY WIRE BRN RED/ WIRE BRN WIRE COMFORT SYSTEM CONTROL MODULE (RIGHT SIDE OF TRUNK) COMPUTER DATA LINES SYSTEM DIRECT SHIFT GEARBOX (DSG) MECHATRONIC DRIVER'S SIDE FUSE PANEL (BEHIND LEFT END OF DASH) ENGINE COMPT) FUSE 1 FUSE CARRIER 1 FUSE 10 GEAR POSITION DISTANCE SENSOR 1 GEAR POSITION DISTANCE SENSOR 2 GEAR POSITION DISTANCE SENSOR 3 GEAR POSITION DISTANCE SENSOR 4 GRN/GRY WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED NCA WIRE ORG/BLK WIRE ORG/BRN WIRE POWER DISTRIBUTION SYSTEM RED/BRN WIRE SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ON SHIFTER UNIT) TEMPERATURE SENSOR (IN CONTROL MODULE) TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION PARK SELECTOR SWITCH, SHIFT LOCK SOLENOID VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
