Audi A4 B7 (2004-2009) wht/blk Wiring diagram
This page shows the only wiring diagram for the component.wht/blk, which is found in the car Audi A4 B7 (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wht/blk (11 of 11)
3 1 AVANT SEDAN
AVANT
BATTERY
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EXCEPT CONVERTIBLE
EXCEPT CONVERTIBLE W/O LIGHT SENSOR
FOG LIGHT SWITCH
FUSE 1
FUSE 17
FUSE 19
FUSE HOLDER
FUSE STRIP (MAIN FUSE) FUSE 88
GRN WIRE
GRY WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HEADLIGHT SWITCH
HIGH BEAM
HOT AT ALL TIMES
LEFT FRONT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LEFT REAR FOG LIGHT (EXCEPT CONVERTIBLE)
LIGHT SWITCH
LOW BEAM
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR (TOP OF WINDSHIELD, IN REARVIEW MIRROR ASSEMBLY)
RED WIRE
RIGHT FRONT FOG LIGHT
RIGHT HEADLIGHT ASSEMBLY
RIGHT REAR FOG LIGHT (EXCEPT CONVERTIBLE)
TURN SIGNAL SWITCH (HEADLIGHT DIMMER/FLASH SWITCH)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component: -> Headlamps & fog lamps circuit, with standard headlights -> WHT/BLK WIRE
