Audi A4 B7 (2004-2009) w/ driver's only power seat Wiring diagram

This page shows the only wiring diagram for the component.w/ driver's only power seat, which is found in the car Audi A4 B7 (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram w/ driver's only power seat (1 of 1)

Wiring diagram w/ driver's only power seat for Audi A4 B7 (2004-2009)

Get access

BLK WIRE BLU WIRE BRN WIRE DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR (IN DRIVER'S SEAT BACK) DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR (IN DRIVER'S SEAT BACK) DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER 2 FUSE 45 FRONT PASSENGER'S SEAT ADJUSTMENT CIRCUIT BREAKER 1 (FUSE 46) HOT AT ALL TIMES LUMBAR CURV- ATURE LUMBAR HEIGHT LUMBAR PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH HEIGHT RED WIRE W/ DRIVER'S ONLY POWER SEAT W/O DRIVER'S POWER SEAT WHT WIRE

Go to component: -> Lumbar circuit, except convertible -> W/ DRIVER'S ONLY POWER SEAT
