Audi A4 B7 (2004-2009) sedan avant 2 1 Wiring diagram
This page shows the only wiring diagram for the component.sedan avant 2 1, which is found in the car Audi A4 B7 (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sedan avant 2 1 (1 of 1)
ALARM HORN
ANTENNA (UNDER LEFT SIDE OF LUGGAGE COMPARTMENT LID)
ANTENNA SELECTION CONTROL MODULE
ANTENNA SUPPRESSION FILTER
ANTI-THEFT IMMOBILIZER INDUCTION COIL (RIGHT SIDE OF STEERING COLUMN)
AVANT
AVANT SEDAN 2 1
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (BELOW DRIVER'S SEAT)
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
EXTERIOR LIGHTS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
FRONT HOOD SWITCH
FUSE 24
FUSE 38
FUSE HOLDER
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT ANTENNA MODULE (UNDER LEFT SIDE OF LUGGAGE COMPARTMENT LID)
LEFT REAR BROKEN WINDOW GLASS SENSOR
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PARKING BRAKE WARNING LIGHT SWITCH
RADIO
REAR WINDOW DEFOGGER
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT REAR BROKEN WINDOW GLASS SENSOR
SEDAN
SEDAN AVANT 2 1
TRUNK LID ALARM SWITCH
TRUNK LOCK ALARM/CENTRAL LOCKING SWITCH
VIO WIRE
VIO/BLU WIRE
W/O RADIO
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Anti-theft circuit, except convertible -> SEDAN AVANT 2 1
