Audi A4 B7 (2004-2009) power windows, interior lights, door locks systems Wiring diagram
This page shows the only wiring diagram for the component.power windows, interior lights, door locks systems, which is found in the car Audi A4 B7 (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power windows, interior lights, door locks systems (1 of 1)
ANTI-THEFT, DOOR LOCKS, POWER WINDOWS, INTERIOR LIGHTS SYSTEMS
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DE- FOG
DRIVER'S SEAT MEMORY PROGRAM CONTROL
DRIVER'S SIDE OUTSIDE FOLDING MIRROR
FOLD- AWAY
FUSE 22
FUSE HOLDER
GRN/BLK WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
MIRROR ADJUSTMENT SWITCH
MIRROR FOLD AWAY SWITCH
MIRROR SELECTOR SWITCH
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER'S SIDE OUTSIDE FOLDING MIRROR
POSITION
POWER WINDOWS, INTERIOR LIGHTS, DOOR LOCKS SYSTEMS
RED/YEL WIRE
Go to component: -> Memory systems circuit, convertible (4 of 4) -> POWER WINDOWS, INTERIOR LIGHTS, DOOR LOCKS SYSTEMS
