Audi A4 B7 (2004-2009) navigation system w/cd drive control module Wiring diagram

6-SPEED CVT BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE CLIMATRONIC CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE CONVERTIBLE EXCEPT CONVERTIBLE CONVERTIBLE TOP CONTROL MODULE (W/ CONV) DATA LINK CONNECTOR EXCEPT CONVERTIBLE CONVERTIBLE EXCEPT SYMPHONY II FUSE 12 FUSE 31 FUSE HOLDER GRN WIRE GRN/BLU WIRE GRN/RED WIRE HIGH/LOW BUS CIRCUIT HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER LEFT ENTRY ASSISTANCE CONTROL MODULE (W/ CONV) MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE MOTRONIC ENGINE CONTROL MODULE (2.0L) NAVIGATION SYSTEM W/CD DRIVE CONTROL MODULE ORG/BLK WIRE ORG/BRN WIRE PARKING AID CONTROL MODULE RADAR INTERIOR MONITORING CONTROL MODULE 1 RADIO RED WIRE RED/BLK WIRE RIGHT ENTRY ASSISTANCE CONTROL MODULE (W/ CONV) TELEPHONE TRANSCEIVER TRANSMISSION CONTROL MODULE (W/ A/T) TUNER FOR NAVIGATION/ TV (W/O CONV) W/ SYMPHONY II W/MEMORY
