Audi A4 B7 (2004-2009) fuse 37 fuse 36 fuse 15 Wiring diagram

AVANT BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/VIO WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 13 FUSE 37 FUSE 36 FUSE 15 FUSE HOLDER GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE HEADLIGHT WASHER PUMP WINDSHIELD WIPER MOTOR HOT AT ALL TIMES HOT AT ALL TIMES FUSE STRIP (MAIN FUSE) FUSE 88 HOT W/ LOAD REDUCTION RELAY ENERGIZED IGNITION/ STARTER SWITCH INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER SYSTEM LOCK ON NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM REAR WINDSHIELD WIPER MOTOR (AVANT) RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (AT LEFT SIDE OF DASH) VIO WIRE W/ AVANT W/ CONVERTIBLE WHT WIRE WINDSHIELD WASHER FLUID LEVEL WARNING SWITCH WINDSHIELD WASHER PUMP WINDSHIELD WIPER/WASHER SWITCH YEL WIRE YEL/BLK WIRE
