Audi A4 B7 (2004-2009) clutch pedal/ starter interlock switch Wiring diagram

This page shows the only wiring diagram for the component.clutch pedal/ starter interlock switch, which is found in the car Audi A4 B7 (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram clutch pedal/ starter interlock switch (1 of 1)

Wiring diagram clutch pedal/ starter interlock switch for Audi A4 B7 (2004-2009)

Get access

BATTERY BLK WIRE BRN WIRE CHARGING CIRCUIT CLUTCH PEDAL/ STARTER INTERLOCK SWITCH FUSE 88 (MAIN FUSE) GRY/WHT WIRE IGNITION/ STARTER SWITCH LOCK OFF LOCKING RELAY FOR STARTER (CLUTCH PEDAL SWITCH) (LEFT REAR OF ENGINE COMPT) NCA WIRE RED WIRE RED/BLK WIRE STARTER

Go to component: -> 2.0l turbo, starting circuit, with m/t -> CLUTCH PEDAL/ STARTER INTERLOCK SWITCH
