Audi A4 B7 (2004-2009) 3 1 avant sedan left rear fog light Wiring diagram

3 1 AVANT SEDAN LEFT REAR FOG LIGHT AVANT BATTERY BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DAYTIME RUNNING LIGHT EXCEPT CONVERTIBLE CONVERTIBLE FUSE 1 FUSE 10 FUSE 17 FUSE HOLDER FUSE STRIP (MAIN FUSE) FUSE 88 GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLIGHT BEAM ADJUSTING MOTOR HEADLIGHT RANGE CONTROL MODULE HIGH INTENSITY GAS DISCHARGE LAMP CONTROL MODULE HIGH/ LOW BEAM SWITCH- OVER SOLENOID HOT AT ALL TIMES HOT IN RUN OR START INTENSITY GAS DISCHARGE LAMP LEFT FRONT FOG LIGHT LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT HEADLIGHT ASSEMBLY LEFT REAR LEVEL CONTROL SYSTEM SENSOR NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR (TOP OF WINDSHIELD, IN REARVIEW MIRROR ASSEMBLY) RED WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE
