Supplemental restraints circuit, without convertible for Audi A4 B6 (2000-2006)

AIR BAG CONTROL MODULE (BELOW CENTER CONSOLE) AIR BAG SPIRAL SPRING/RETURN SPRING W/SLIP RING BLK WIRE BLU WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (NEAR BASE OF LEFT FRONT SEAT, IN E-BOX) DRIVER'S SIDE AIR BAG IGNITER DRIVER'S SIDE HEAD AIR BAG IGNITER (IF EQUIPPED) DRIVER'S SIDE SIDE AIR BAG IGNITER DRIVER'S SIDE SIDE REAR AIR BAG IGNITER GRN WIRE GRY (OR BRN) WIRE GRY WIRE HOT AT ALL TIMES IGNITION/ STARTER SWITCH LEFT REAR SEAT BELT TENSIONER IGNITER LOW BUS HIGH BUS NCA WIRE OFF ORG/BLK WIRE ORG/BRN WIRE PASSENGER'S SIDE AIR BAG IGNITER 1 PASSENGER'S SIDE HEAD AIR BAG IGNITER (IF EQUIPPED) PASSENGER'S SIDE SIDE AIR BAG IGNITER PASSENGER'S SIDE SIDE REAR AIR BAG IGNITER RED WIRE RIGHT REAR SEAT BELT TENSIONER IGNITER RUN WIRE SEDAN ONLY SHORTING CONTACT SOLID STATE TELEPHONE/TELEMATIC CONTROL MODULE (NEAR BASE OF RIGHT FRONT SEAT, IN E BOX) VIO WIRE VIO/BLU WIRE WHT (OR VIO) WIRE WHT (OR YEL) WIRE WHT WIRE YEL (OR BRN) WIRE YEL WIRE

65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 SOLID STATE AIR BAG CONTROL MODULE (BELOW CENTER CONSOLE) AIR BAG MALFUNCTION INDICATOR LAMP (MIL) BLK WIRE BLU WIRE BRN WIRE CENTER REAR SEAT BELT TENSIONER IGNITER DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) DRIVER'S FRONT AIR BAG CRASH SENSOR (NEAR LEFT HEADLIGHT) DRIVER'S SEAT BELT TENSIONER IGNITER 1 DRIVER'S SIDE SIDE AIR BAG CRASH SENSOR (INSIDE LEFT "B" PILLAR) FRONT INTERIOR LIGHT GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE INSTRUMENT CLUSTER LEFT SEAT BELT SWITCH NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE PASS SIDE AIR BAG OFF IND PASSENGER'S FRONT AIR BAG CRASH SENSOR (NEAR RIGHT HEADLIGHT) PASSENGER'S SEAT BELT TENSIONER IGNITER 2 PASSENGER'S SIDE SIDE AIR BAG CRASH SENSOR (INSIDE RIGHT "B" PILLAR) RED WIRE RIGHT SEAT BELT SWITCH SHORTING CONTACT SOLID STATE VIO WIRE VIO/BLU WIRE WHT WIRE WHT/YEL WIRE YEL WIRE
