Audi A4 B6 (2000-2006) trunk lid release switch wiring diagram
This page shows the only wiring diagram for the component.trunk lid release switch, which is found in the car Audi A4 B6 (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
trunk lid release switch wiring diagram (1 of 1)
BLU WIRE
BLU/BRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR WINDOW REGULATOR SWITCHES
DRIVER SIDE DOOR CONTROL MODULE (INTEGRAL WITH WINDOW REGULATOR MOTOR)
DRIVER SIDE DOOR OPENER LIGHTING
DRIVER SIDE INTERIOR LOCK SWITCH
DRIVER'S SEAT MEMORY PROGRAM SWITCH
MIRROR ADJUSTMENT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER COMPARTMENT MONITORING SWITCH
PASSENGER DOOR CONTROL MODULE (INTEGRAL WITH WINDOW REGULATOR MOTOR)
PASSENGER DOOR WINDOW REGULATOR SWITCH
PASSENGER SIDE DOOR OPENER LIGHTING
PASSENGER SIDE INTERIOR LOCK SWITCH
POWER WINDOWS, MIRRORS, DOOR LOCKS SYSTEMS, COURTESY LAMPS CIRCUIT
TRUNK LID RELEASE SWITCH
Go to component -> Instrument illumination circuit, with convertible (2 of 2) -> TRUNK LID RELEASE SWITCH
