Audi A4 B6 (2000-2006) starting system (starter) wiring diagram
This page shows the only wiring diagram for the component.starting system (starter), which is found in the car Audi A4 B6 (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
starting system (starter) wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
EXTERIOR LIGHTS SYSTEM (BACKUP LIGHTS)
FUSE 31
FUSE 5
FUSE FOR AUTOMATIC TRANSMISSION FUSE 86
FUSE HOLDER (LEFT END OF DASH)
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ ECM RELAY ENERGIZED
IGNITION SWITCH
INSTRUMENT CLUSTER
OFF
ORG/BLK WIRE
ORG/BRN WIRE
PARK/ NEUTRAL POSITION (PNP) RELAY (ON E-BOX RELAY CARRIER)
RED WIRE
RED/GRN WIRE
RUN WIRE
SHIFT LOCK SOLENOID (ON SHIFT LEVER ASSEMBLY)
STARTING SYSTEM (STARTER)
TIPTRONIC SWITCH (IN SHIFT MECHANISM COVER)
TRANSMISSION CONTROL MODULE (TCM)
WHT WIRE
YEL WIRE
Go to component -> A/t circuit, with cvt -> STARTING SYSTEM (STARTER)
