Audi A4 B6 (2000-2006) starter interlock alarm system relay Wiring diagram

This page shows the only wiring diagram for the component.starter interlock alarm system relay, which is found in the car Audi A4 B6 (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram starter interlock alarm system relay (1 of 1)

Wiring diagram starter interlock alarm system relay for Audi A4 B6 (2000-2006)

Get access

BATTERY BLK WIRE BRN WIRE CHARGING CIRCUIT FUSE STRIP (MAIN FUSE) FUSE 88 IGNITION/ STARTER SWITCH MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH NCA WIRE OFF RED WIRE RED/BLK WIRE RUN WIRE STARTER STARTER INTERLOCK ALARM SYSTEM RELAY YEL WIRE

Go to component: -> Starting circuit, 5 speed a/t -> STARTER INTERLOCK ALARM SYSTEM RELAY
