Audi A4 B6 (2000-2006) right rear door opener lighting Wiring diagram
This page shows the only wiring diagram for the component.right rear door opener lighting, which is found in the car Audi A4 B6 (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear door opener lighting (1 of 1)
ANTI-SLIP CONTROL SWITCH
ASHTRAY LIGHT
BATTERY
BLK WIRE
BLU WIRE
BOARD COMPUTER FUNCTION SELECTOR SWITCH II
BRN WIRE
CENTER ARMREST ILLUMINATION
CENTER INSTRUMENT PANEL VENT ILLUMINATION
CIGARETTE LIGHTER
COIN HOLDER ILLUMINATION
COMPUTER DATA LINES SYSTEM
CUP HOLDER ILLUMINATION
FRONT INTERIOR LIGHT ASSEMBLY
FUSE STRIP (MAIN FUSE) FUSE 88
GARAGE DOOR OPENER CONTROL HEAD
GRN WIRE
GRY WIRE
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT INSTRUMENT PANEL VENT ILLUMINATION
LEFT REAR DOOR OPENER LIGHTING
LEFT REAR HEATED SEAT CONTROL MODULE
LIGHT SWITCH
LUGGAGE COMPARTMENT LIGHT (AVANT)
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RADIO CONNECTOR
REAR CENTER ASHTRAY LIGHT
REAR WINDOW SHADE SWITCH
RED WIRE
RIGHT INSTRUMENT PANEL VENT ILLUMINATION
RIGHT REAR DOOR OPENER LIGHTING
RIGHT REAR HEATED SEAT CONTROL MODULE
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (IN TOP OF STEERING COLUMN)
STORAGE COMPARTMENT ILLUMINATION
TIPTRONIC SWITCH (IF EQUIPPED)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
YEL WIRE
Go to component: -> Instrument illumination circuit, without convertible (1 of 2) -> RIGHT REAR DOOR OPENER LIGHTING
