Audi A4 B6 (2000-2006) rear lid remote control release switch Wiring diagrams

This page contains all the electrical diagrams for the component. rear lid remote control release switch, in which he is found in the car Audi A4 B6 (2000-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear lid remote control release switch (1 of 2)

Wiring diagram rear lid remote control release switch for Audi A4 B6 (2000-2006)

Get access

BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUEL TANK LID UNLOCK MOTOR FUEL TANK SWITCH GRN WIRE GRY WIRE INSTRUMENT CLUSTER ORG/ WIRE REAR LID REMOTE CONTROL RELEASE SWITCH REAR LID UNLOCK MOTOR RED WIRE VIO WIRE YEL WIRE

Go to component: -> Trunk & fuel door release circuit, with convertible -> REAR LID REMOTE CONTROL RELEASE SWITCH

Wiring diagram rear lid remote control release switch (2 of 2)

Wiring diagram rear lid remote control release switch for Audi A4 B6 (2000-2006)

Get access

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUEL TANK LID UNLOCK MOTOR GRN WIRE GRY WIRE ORG/ WIRE REAR LID LOCK CYLINDER SWITCH REAR LID REMOTE CONTROL RELEASE SWITCH REAR LID UNLOCK MOTOR RED WIRE REMOTE POWER FUEL TANK LID RELEASE INFO NOT AVAILABLE VIO WIRE YEL WIRE

Go to component: -> Trunk & fuel door release circuit, without convertible -> REAR LID REMOTE CONTROL RELEASE SWITCH
