Audi A4 B6 (2000-2006) multi- function transmission range (tr) switch Wiring diagrams

This page contains all the electrical diagrams for the component. multi- function transmission range (tr) switch, in which he is found in the car Audi A4 B6 (2000-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

multi- function transmission range (tr) switch wiring diagram (1 of 4)

A/T BACK-UP BACK-UP LIGHT SWITCH BLK WIRE BLU WIRE BRN WIRE FUSE 31 FUSE HOLDER (LEFT END OF DASH) GRN WIRE HOT IN RUN OR START LEFT TAILLAMP ASSEMBLY M/T MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH ORG/ WIRE RED WIRE RIGHT TAILLAMP ASSEMBLY VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)

Go to component -> Backup lamps circuit, avant (high line) -> MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH

multi- function transmission range (tr) switch wiring diagram (2 of 4)

A/T BACK-UP BACK-UP LIGHT SWITCH BLK WIRE BLU WIRE BRN WIRE FUSE 31 FUSE HOLDER (LEFT END OF DASH) HOT IN RUN OR START LEFT TAILLAMP ASSEMBLY M/T MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH RED WIRE RIGHT TAILLAMP ASSEMBLY

Go to component -> Backup lamps circuit, avant (low line) -> MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH

multi- function transmission range (tr) switch wiring diagram (3 of 4)

A/T W/ CVT A/T W/O CVT BACK-UP BACK-UP LIGHT SWITCH BLK WIRE BLU WIRE BRN WIRE FUSE 31 FUSE HOLDER (LEFT END OF DASH) GRN WIRE HOT IN RUN OR START LEFT TAILLAMP ASSEMBLY M/T MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH ORG/ WIRE PARK/NEUTRAL POSITION (PNP) RELAY (RELAY CARRIER E-BOX) RED WIRE RIGHT TAILLAMP ASSEMBLY VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) YEL WIRE

Go to component -> Backup lamps circuit, without convertible, sedan -> MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH

multi- function transmission range (tr) switch wiring diagram (4 of 4)

BATTERY BLK WIRE BRN WIRE CHARGING CIRCUIT FUSE STRIP (MAIN FUSE) FUSE 88 IGNITION/ STARTER SWITCH MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH NCA WIRE OFF RED WIRE RED/BLK WIRE RUN WIRE STARTER STARTER INTERLOCK ALARM SYSTEM RELAY YEL WIRE

Go to component -> Starting circuit, 5 speed a/t -> MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH

Audi A4 B6 (2000-2006) multi- function transmission range (tr) switch Wiring diagrams

multi- function transmission range (tr) switch wiring diagram (1 of 4)

List of components:

multi- function transmission range (tr) switch wiring diagram (2 of 4)

List of components:

multi- function transmission range (tr) switch wiring diagram (3 of 4)

List of components:

multi- function transmission range (tr) switch wiring diagram (4 of 4)

List of components:
