Audi A4 B6 (2000-2006) fold- away Wiring diagrams

This page contains all the electrical diagrams for the component. fold- away, in which he is found in the car Audi A4 B6 (2000-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram fold- away (1 of 2)

Wiring diagram fold- away for Audi A4 B6 (2000-2006)

Get access

BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DE- FOG DRIVER SIDE DOOR CONTROL MODULE MODULE (INTEGRAL WITH WINDOW REGULATOR MOTOR) DRIVER'S SEAT MEMORY PROGRAM CONTROL DRIVER'S SIDE OUTSIDE FOLDING MIRROR FOLD- AWAY FUSE 22 FUSE HOLDER (LEFT END OF DASH) GRN/BLK WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES MIRROR ADJUSTMENT SWITCH MIRROR FOLD AWAY SWITCH MIRROR SELECTOR SWITCH NCA WIRE ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE DOOR CONTROL MODULE (INTEGRAL WITH WINDOW REGULATOR MOTOR) PASSENGER'S SIDE OUTSIDE FOLDING MIRROR POSITION RED/YEL WIRE

Go to component: -> Memory systems circuit, with convertible (4 of 4) -> FOLD- AWAY

Wiring diagram fold- away (2 of 2)

Wiring diagram fold- away for Audi A4 B6 (2000-2006)

Get access

BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DE- FOG DRIVER SIDE DOOR CONTROL MODULE MODULE (INTEGRAL WITH WINDOW REGULATOR MOTOR) DRIVER'S SEAT MEMORY PROGRAM CONTROL DRIVER'S SIDE OUTSIDE FOLDING MIRROR FOLD- AWAY FUSE 22 FUSE HOLDER (LEFT END OF DASH) GRN/BLK WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES MIRROR ADJUSTMENT SWITCH MIRROR FOLD AWAY SWITCH MIRROR SELECTOR SWITCH NCA WIRE ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE DOOR CONTROL MODULE (INTEGRAL WITH WINDOW REGULATOR MOTOR) PASSENGER'S SIDE OUTSIDE FOLDING MIRROR POSITION RED/YEL WIRE

Go to component: -> Memory systems circuit, without convertible (2 of 2) -> FOLD- AWAY
