Audi A4 B6 (2000-2006) convertible top locking motor wiring diagram
This page shows the only wiring diagram for the component.convertible top locking motor, which is found in the car Audi A4 B6 (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
convertible top locking motor wiring diagram (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP COMPARTMENT COVER LOCKING MOTOR
CONVERTIBLE TOP COMPARTMENT LATCH SWITCH
CONVERTIBLE TOP FRAME POSITION SENSOR
CONVERTIBLE TOP LOCK SWITCH (CLOSED)
CONVERTIBLE TOP LOCK SWITCH (OPEN)
CONVERTIBLE TOP LOCKING MOTOR
CONVERTIBLE TOP OPERATION CONTROL MODULE (AT RIGHT QUARTERPANEL, BEHIND TRIM)
CONVERTIBLE TOP OPERATION SWITCH
DEFOGGER SYSTEM
FUSE
FUSE HOLDER (LEFT END OF DASH)
GRN/BLK WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
VIO WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/YEL WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Convertible top circuit (1 of 2) -> CONVERTIBLE TOP LOCKING MOTOR
