Power windows circuit for Audi A4 B5 facelift (1999-2001)

Power windows circuit (1 of 2)

A4 Audi B5 facelift (1999-2001): Power windows circuit (1 of 2)

Get access

8-WAY RELAY CARRIER BLK WIRE BLK/YEL WIRE BRN WIRE HOT AT ALL TIMES IGNITION SWITCH LEFT FRONT WINDOW SWITCH LEFT WINDOW MOTOR OFF POWER SUNROOF CONTROL MODULE POWER WINDOW FUSE 37 RED WIRE RED/BLK WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RUN WIRE WHT/YEL WIRE WINDOW MOTOR YEL/BLU WIRE

Power windows circuit (2 of 2)

A4 Audi B5 facelift (1999-2001): Power windows circuit (2 of 2)

Get access

8-WAY RELAY CARRIER BLK WIRE BRN WIRE CIRCUIT BREAKER 43 GRN WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES POWER WINDOW LEFT REAR DOOR WINDOW MOTOR LEFT REAR DOOR WINDOW SWITCH (CENTER CONSOLE) LEFT REAR DOOR WINDOW SWITCH (DOOR) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RIGHT FRONT DOOR WINDOW SWITCH RIGHT FRONT DOOR WINDOW SWITCH (RIGHT DOOR) RIGHT REAR DOOR WINDOW MOTOR RIGHT REAR DOOR WINDOW SWITCH (CENTER CONSOLE) RIGHT REAR DOOR WINDOW SWITCH (DOOR) RIGHT WINDOW MOTOR WHT WIRE WHT/BLK WIRE WHT/VIO WIRE WHT/YEL WIRE WINDOW LOCKOUT SWITCH WINDOW MOTOR YEL WIRE
