Audi A4 B5 facelift (1999-2001) trunk lid release switch Wiring diagrams
This page contains all the electrical diagrams for the component. trunk lid release switch, in which he is found in the car Audi A4 B5 facelift (1999-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trunk lid release switch (1 of 2)
ALARM HORN
ANTENNA
AVANT
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/WHT (OR BRN/BLK) WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUTCH PEDAL POSITION SWITCH (M/T)
DOOR LOCK SWITCH
EXTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM
FUSE
FUSE PANEL (ON LEFT END OF DASH) FUSE
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN START, RUN
IGNITION SWITCH
INSTRUMENT CLUSTER
KEY SWITCH
LEFT DOOR WARNING LIGHT
LUGGAGE COMPT LIGHT
MULTI- FUNCTION TRANSMISSION SWITCH (A/T)
NCA WIRE
PARK/ NEUTRAL POSITION RELAY
POWER WINDOWS SYSTEM
POWER WINDOWS SYSTEM INTERIOR LIGHTS SYSTEM
RADIO
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT DOOR WARNING LIGHT
TAILGATE RELEASE SYSTEMS
TRUNK LID ALARM SWITCH
TRUNK LID RELEASE SWITCH
VIO/BLU WIRE
WARNING LIGHT CONTROL MODULE
WHT WIRE
WHT/BLU WIRE
WITH REMOTE CONTROL
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Anti-theft circuit (1 of 2) -> TRUNK LID RELEASE SWITCH
Wiring diagram trunk lid release switch (2 of 2)
Go to component -> Trunk release circuit -> TRUNK LID RELEASE SWITCH
