Audi A4 B5 facelift (1999-2001) right rear woofer, midrange speaker Wiring diagram
This page shows the only wiring diagram for the component.right rear woofer, midrange speaker, which is found in the car Audi A4 B5 facelift (1999-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear woofer, midrange speaker (1 of 1)
1 2 3 4 5 6 7 8 9 10 (NAVIGATION ONLY)
ANTENNA
ANTI-THEFT SYSTEM
AUTO CHECK SYSTEM
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/RED WIRE
CD CHANGER UNIT
COMBINATION PROCESSOR
COMPUTER DATA LINES SYSTEM
FUSE 37
FUSE 5
FUSE PANEL (ON LEFT END OF DASH)
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT FREQUENCY CROSSOVER
LEFT FRONT WOOFER, MIDRANGE SPEAKER
LEFT REAR WOOFER, MIDRANGE SPEAKER
LEFT REAR WOOFER/ AMPLIFIER
MULTIFUNCTION STEERING WHEEL CONTROL MODULE
NAVIGATION CONTROL MODULE (IF EQUIPPED)
NCA WIRE
RADIO
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW DEFOGGER/ WINDOW ANTENNA (W/ SYMPHONY RADIO)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL (OR WHT/YEL) WIRE
RED/YEL WIRE
RIGHT FREQUENCY CROSSOVER
RIGHT FRONT WOOFER, MIDRANGE SPEAKER
RIGHT REAR WOOFER, MIDRANGE SPEAKER
TELEPHONE TRANSCEIVER
TV ANTENNA AMPLIFIER 2
TV ANTENNA AMPLIFIER 3
TV ANTENNA AMPLIFIER 4
VIO WIRE
VIO/GRY WIRE
W/ AUTO CHECK SYSTEM
W/ CONCERT RADIO
W/ SYMPHONY RADIO
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Am/fm stereo circuit, with cd changer with avant -> RIGHT REAR WOOFER, MIDRANGE SPEAKER
