Audi A4 B5 facelift (1999-2001) left make-up mirror switch Wiring diagram
This page shows the only wiring diagram for the component.left make-up mirror switch, which is found in the car Audi A4 B5 facelift (1999-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left make-up mirror switch (1 of 1)
AUTOMATIC DAY/NIGHT MIRROR
AVANT
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DOOR WARNING LIGHTS CONTROL MODULE (ON 8-WAY RELAY CARRIER)
DRIVER SIDE HEATED MIRROR
DRIVER'S SIDE DOOR CONTACT SWITCH
DRIVER'S SIDE DOOR WARNING LIGHT
FRONT INTERIOR LIGHT ASSEMBLY
FUSE 14
FUSE 3 FUSE 5
FUSE 38
FUSE PANEL (BEHIND LEFT SIDE OF DASH)
GLOVE COMPT LIGHT MIRROR ADJUSTMENT SWITCH
GRN WIRE
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEAD PARK HEADLIGHTS, EXTERIOR LIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
INTERIOR LIGHTS SYSTEM (INSTRUMENT ILLUMINATION CIRCUIT)
LEFT FOOT- WELL LIGHT
LEFT LUGGAGE COMPARTMENT LIGHT
LEFT MAKE-UP MIRROR LIGHT
LEFT MAKE-UP MIRROR SWITCH
LEFT REAR DOOR CONTACT SWITCH
LEFT REAR DOOR WARNING LIGHT
LIGHT SWITCH
LUGGAGE COMPARTMENT LIGHT
MICRO CENTRAL ELECTRIC
OFF
PASSENGER'S FRONT DOOR CONTACT SWITCH
PASSENGER'S SIDE DOOR WARNING LIGHT
REAR READING/ COURTESY LIGHT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOOT- WELL LIGHT
RIGHT LUGGAGE COMPARTMENT LIGHT
RIGHT MAKE-UP MIRROR LIGHT
RIGHT MAKE-UP MIRROR SWITCH
RIGHT REAR DOOR CONTACT SWITCH
RIGHT REAR DOOR WARNING LIGHT
TRUNK LOCK SWITCH (SEDAN,
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamp circuit -> LEFT MAKE-UP MIRROR SWITCH
