Audi A4 B5 facelift (1999-2001) left head/ foglight assembly Wiring diagram
This page shows the only wiring diagram for the component.left head/ foglight assembly, which is found in the car Audi A4 B5 facelift (1999-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left head/ foglight assembly (1 of 1)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
EXTERIOR LIGHTS
FOGLIGHT CONTROL MODULE
FRONT FOG LIGHT SWITCH
FTP
FUSE 19
FUSE FUSE
FUSE PANEL FUSE
FUSE PANEL FUSE 3
GRN WIRE
GRY WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HEAD
HEAD- LIGHT
HEAD- LIGHT FOG LIGHT FOG LIGHT
HEADLIGHT DIMMER/ FLASHER SWITCH
HEADLIGHTS SYSTEM (HEADLAMPS LEVELING CIRCUIT)
HI BEAM
HI FTP LO
HI HEAD LO
HI LO
HOT AT ALL TIMES
IGNITION SWITCH
IND
INSTRUMENT CLUSTER
LEFT HEAD/ FOGLIGHT ASSEMBLY
LEFT TAILLIGHT ASSEMBLY LEFT REAR FOG LIGHT
LIGHT SWITCH
LO HI
LOAD REDUCTION RELAY
MICRO CENTRAL ELECTRIC
NOT USED
OFF
OFF HEAD PARK
OFF PARK
REAR FOG LIGHT SWITCH
REAR LAMP CONTROL MODULE
RED WIRE
RIGHT HEAD/ FOGLIGHT ASSEMBLY
RIGHT TAILLIGHT ASSEMBLY
RUN WIRE
VIO WIRE
W/ AUTO CHECK SYSTEM W/ AUTO CHECK SYSTEM W/O AUTO CHECK SYSTEM
W/DRL ONLY
W/O AUTO CHECK SYSTEM
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Headlamps circuit -> LEFT HEAD/ FOGLIGHT ASSEMBLY
