Audi A4 B5 facelift (1999-2001) front height Wiring diagram
This page shows the only wiring diagram for the component.front height, which is found in the car Audi A4 B5 facelift (1999-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front height (1 of 1)
BACK- REST
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT BREAKER 44
DRIVER'S SEAT BACKREST ADJUSTING MOTOR
DRIVER'S SEAT FORE/AFT ADJUSTING MOTOR
DRIVER'S SEAT FRONT HEIGHT ADJUSTING MOTOR
DRIVER'S SEAT REAR HEIGHT ADJUSTING MOTOR
DRIVER'S SEAT SWITCH
FORE/ AFT
FRONT HEIGHT
FUSE PANEL (ON LEFT END OF DASH)
GRN WIRE
HOT AT ALL TIMES
REAR HEIGHT
RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Left power seat circuit -> FRONT HEIGHT
