Audi A4 B5 facelift (1999-2001) emergency flasher switch relay Wiring diagram
This page shows the only wiring diagram for the component.emergency flasher switch relay, which is found in the car Audi A4 B5 facelift (1999-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram emergency flasher switch relay (1 of 1)
AIR BAG CONTROL MODULE (IN CENTER CONSOLE)
AIR BAG MALFUNCTION INDICATOR LAMP (MIL)
AIR BAG SPIRAL SPRING/ RETURN SPRING (W/SLIP RING)
BLK WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CENTER REAR SEAT BELT TENSIONER IGNITER (AVANT)
DRIVER'S SEAT BELT TENSIONER IGNITER
DRIVER'S SIDE AIR BAG IGNITER
DRIVER'S SIDE SIDE AIR BAG IGNITER
EMERGENCY FLASHER SWITCH RELAY
GRN WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
IGNITION/ STARTER SWITCH
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER COMBINATION PROCESSOR
LEFT REAR SEAT BELT TENSIONER IGNITER
LOCK
NCA WIRE
PASSENGER'S SEAT BELT TENSIONER IGNITER DRIVER'S SIDE AIR BAG CRASH SENSOR
PASSENGER'S SIDE AIR BAG CRASH SENSOR (BELOW LEFT SIDE OF DASH)
PASSENGER'S SIDE AIR BAG IGNITER 1
PASSENGER'S SIDE HEAD AIR BAG IGNITER (W/HEAD AIR BAG)
PASSENGER'S SIDE SIDE AIR BAG IGNITER
RED WIRE
RIGHT REAR SEAT BELT TENSIONER IGNITER
RUN WIRE
SOLID STATE
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit -> EMERGENCY FLASHER SWITCH RELAY
