Audi A4 B5 (1994-1999) Automatic a/c circuit

A/C COMPRESSOR SPEED SENSOR A/C CONTROL HEAD ANTI-THEFT SYSTEM BACK PRESSURE FLAP MOTOR AND SENSOR BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/VIO WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER OUTLET TEMPERATURE SENDER CENTRAL FLAP MOTOR AND SENSOR FLOOR OUTLET TEMPERATURE SENDER FOOTWELL/DEFROSTER FLAP MOTOR AND SENSOR FRESH AIR INTAKE DUCT TEMPERATURE SENSOR FUSE PANEL GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES FUSE 15 INSTRUMENT CLUSTER INTERIOR TEMPERATURE FAN, SENSOR MOTRONIC ENGINE CONTROL MODULE OUTSIDE AIR TEMPERATURE RED/BLU WIRE RED/YEL WIRE SENSOR SUNLIGHT PHOTO SENSOR TEMPERATURE REGULATOR FLAP MOTOR AND SENSOR TRANSMISSION CONTROL MODULE WHT/BLU WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/WHT WIRE

A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY (IN RELAY CARRIER) A/C REFRIGERANT HIGH PRESSURE SWITCH/COOLANT FAN CONTROL THERMAL SWITCH BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE COOLANT FAN COOLANT FAN CONTROL RELAY COOLANT FAN CONTROL SERIES RESISTOR COOLANT FAN CONTROL THERMAL SWITCH DIGITAL OUTSIDE AIR TEMPERATURE/ TRANSMISSION RANGE SELECTOR LEVER DISPLAY FRESH AIR BLOWER FUSE 25 FUSE 42 FUSE 5 FUSE 51 FUSE PANEL GRN/BLK WIRE GRN/BRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN RUN FUSE 5 HOT W/ LOAD REDUCTION RELAY ENERGIZED RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RELAY CARRIER (8-WAY) SECOND SPEED COOLANT FAN CONTROL RELAY
