Audi A4 B5 (1994-1999) ultra sound sensors control module Wiring diagram

This page shows the only wiring diagram for the component.ultra sound sensors control module, which is found in the car Audi A4 B5 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram ultra sound sensors control module (1 of 1)

Wiring diagram ultra sound sensors control module for Audi A4 B5 (1994-1999)

Get access

ALARM IND BLK WIRE BLK/RED WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE INTERIOR MONITORING SWITCH LEFT FRONT DOOR CONTACT SWITCH LEFT REAR DOOR CONTACT SWITCH LEFT ULTRA- SOUND SENSOR NCA WIRE REAR FOG LOGHT SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RIGHT FRONT DOOR CONTACT SWITCH RIGHT REAR DOOR CONTACT SWITCH RIGHT ULTRA- SOUND SENSOR ULTRA SOUND SENSORS CONTROL MODULE WHT WIRE YEL WIRE

Go to component: -> Anti-theft & central locking circuit (2 of 2) -> ULTRA SOUND SENSORS CONTROL MODULE
