Audi A4 B5 (1994-1999) temperature/ transmission range switch, mirror adjustment motors Wiring diagram
This page shows the only wiring diagram for the component.temperature/ transmission range switch, mirror adjustment motors, which is found in the car Audi A4 B5 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram temperature/ transmission range switch, mirror adjustment motors (1 of 1)
A/C CONTROL HEAD
ABS HYDRAULIC UNIT
BLK WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRN WIRE
CENTRAL ELECTRIC PANEL
CIRCUIT BREAKER 37
CIRCUIT BREAKER 43
CIRCUIT BREAKER 44
DATA LINK CONNECTOR
DUAL HORN RELAY
EMERGENCY FLASHER SWITCH
FRESH AIR BLOWER, A/C CLUTCH RELAY, A/C REFRIGERANT SWITCH
FROM FUEL PUMP RELAY (DIAGRAM 1 OF 2)
FROM IGNITION SWITCH (DIAGRAM 1 OF 2)
FUSE 1
FUSE 12
FUSE 13
FUSE 14
FUSE 15 FUSE 38
FUSE 2
FUSE 24
FUSE 25
FUSE 26
FUSE 39
FUSE 40
FUSE 41
FUSE 51 FUSE 42
FUSE 53
FUSE 9
FUSE PANEL
FUSE/ RELAY PANEL
GRN WIRE
INSTRUMENT CLUSTER, SELECTOR LEVER LIGHT RELAY, TRANSMISSION CONTROL MODULE
LOAD REDUCTION RELAY
POWER SEAT SWITCH
REAR WINDOW DEFOGGER SWITCH
RED WIRE
SECOND SPEED COOLANT FAN CONTROL RELAY, COOLANT FAN CONTROL RELAY
TEMPERATURE/ TRANSMISSION RANGE SWITCH, MIRROR ADJUSTMENT MOTORS
WASHER NOZZLE HEATERS
WASHER/ WIPER INTERMITTENT RELAY
WHT WIRE
WINDOW MOTORS
WINDSHIELD WIPER INTERMITTENT SWITCH
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component: -> Power distribution circuit (2 of 2) -> TEMPERATURE/ TRANSMISSION RANGE SWITCH, MIRROR ADJUSTMENT MOTORS
