Audi A4 B5 (1994-1999) right front speaker Wiring diagram
This page shows the only wiring diagram for the component.right front speaker, which is found in the car Audi A4 B5 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front speaker (1 of 1)
AMPLIFIER
ANTENNA AMPLIFIER
AUTO CHECK SYSTEM
BLK WIRE
BRN WIRE
BRN/GRY WIRE
DEFOGGER SYSTEM
FUSE 237
FUSE HOLDER
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SPEAKER
LEFT REAR MIDRANGE SPEAKER
LEFT REAR WOOFER
LOCK
MIDRANGE
NCA WIRE
RADIO
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/YEL WIRE
RIGHT FRONT SPEAKER
RIGHT REAR MIDRANGE SPEAKER
RIGHT REAR WOOFER
RUN WIRE
WHT WIRE
WHT/BLU WIRE
WOOFER
YEL WIRE
Go to component -> Radio circuit -> RIGHT FRONT SPEAKER
