Audi A4 B5 (1994-1999) mirror adjustment switch Wiring diagrams
This page contains all the electrical diagrams for the component. mirror adjustment switch, in which he is found in the car Audi A4 B5 (1994-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mirror adjustment switch (1 of 4)
A/12
B/6
BLK WIRE
BLU WIRE
BRN WIRE
C/6
C/7
CENTRAL LOCKING/ ALARM SYSTEM/ INTERIOR LIGHT DELAY CONTROL MODULE
DOOR
DOOR DOOR
DRIVER SIDE MIRROR
FRONT INTERIOR LIGHT ASSEMBLY
FUSE 14
FUSE 3
FUSE 5
FUSE PANEL
GLOVE COMPT LIGHT
GRN WIRE
GRY WIRE
HEAD OFF PARK
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER COMBINATION PROCESSOR
LEFT FRONT DOOR CONTACT SWITCH
LEFT LUGGAGE COMPARTMENT LIGHT
LEFT MAKE-UP MIRROR LIGHT
LEFT REAR DOOR CONTACT SWITCH
LEFT REAR READING LIGHT
LIGHT SWITCH
MIRROR ADJUSTMENT SWITCH
NCA WIRE
OFF
RED WIRE
RIGHT FRONT DOOR CONTACT SWITCH
RIGHT LUGGAGE COMPARTMENT LIGHT
RIGHT MAKE-UP MIRROR LIGHT
RIGHT REAR DOOR CONTACT SWITCH
RIGHT REAR READING LIGHT
SWITCH
ULTRA- SOUND SENSOR CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit -> MIRROR ADJUSTMENT SWITCH
Wiring diagram mirror adjustment switch (2 of 4)
ANTENNA AMPLIFIER
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
DRIVER SIDE HEATED MIRROR
ENGINE CONTROL MODULE
FUSE
FUSE PANEL
GRY WIRE
HOT IN RUN
HOT IN RUN OR ACC
ILLUM
MIRROR ADJUSTMENT SWITCH
NCA WIRE
ON IND.
PASS. SIDE HEATED MIRROR
QUATTRO
RADIO
REAR DEFOGGER SWITCH
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW DEFOGGER W/ WINDOW ANTENNA
RED WIRE
SOLID STATE
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit, with antenna amplifier -> MIRROR ADJUSTMENT SWITCH
Wiring diagram mirror adjustment switch (3 of 4)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
DRIVER SIDE HEATED MIRROR
ENGINE CONTROL MODULE
FUSE
FUSE PANEL
GRY WIRE
HOT IN RUN
HOT IN RUN OR ACC
ILLUM
MIRROR ADJUSTMENT SWITCH
ON IND.
PASS. SIDE HEATED MIRROR
QUATTRO
REAR DEFOGGER SWITCH
REAR WINDOW DEFOGGER (HEAT ELEMENT)
REAR WINDOW DEFOGGER SWITCH
RED WIRE
SOLID STATE
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit, without antenna amplifier -> MIRROR ADJUSTMENT SWITCH
Wiring diagram mirror adjustment switch (4 of 4)
Go to component -> Power mirrors circuit -> MIRROR ADJUSTMENT SWITCH
